ASUS P8Z77-V PRO

$229 – ASUS P8Z77-V PRO is an Intel 7 series mother board. Socket H2 (LGA1155)

At this time the product has 2 great reviews on Tigerdirect and 1 negative review. Read Reviews here

Prices change all the time.  View Current Price on TigerDirect Here

Support Page including Drivers and documentation can be found here

Newegg.com shows plenty of overall positive reviews of this product.

Quick Facts:

Brand: Asus

Model: P8Z77-V PRO

CPU Socket: LGA 1155

CPU Type: Core i7 / i5 / i3

Chipsets: Intel Z77

Number of Memory Slots: 4×240pin

Mem Max: 32GB (DDR3 2600(O.C.)/2400(O.C.)/2200(O.C.)/2133(O.C.)/2000(O.C.)/1866(O.C.)/1800(O.C.)/1600/1333) Duel Channel

PCIE 3.0 (x16/0 or x8/x8): 2 slots

PCIE 2.0: 1 slot

PCI Slots: 2

SATA 3Gb/s: 4

SATA 6Gb/s: 4

SATA RAID: 2 x SATA 6Gb/s ports with RAID 0,1,5,10 support, 4 x SATA 3Gb/s ports with RAID 0,1,5,10 support

Audio chipset is a Realtek ALC892 with 8 channels. Comes with a 1GB land port and includes a Wireless N lan card. Includes a single HDMI and Display port. 2 USB 2.0 and 4 USB 3.0 ports

Internal I/O Connectors

Onboard USB
4 x USB 3.0 + 8 x USB 2.0
Other Connectors
1 x CPU Fan connector(s)4 x Chassis Fan connector(s)1 x Optional Fan connector(s)1 x S/PDIF out header(s)1 x 24-pin EATX Power connector(s)1 x 8-pin ATX 12V Power connector(s)

1 x Front panel audio connector(s) (AAFP)

1 x System panel(s)

1 x MemOK! button(s)

1 x TPU switch(es)

1 x EPU switch(es)

1 x Clear CMOS jumper(s)

1 x USB BIOS Flashback button(s)

Size of board: 12.0″ x 9.6″

Asus makes great boards. As with all electronics you get hit’s and misses and sometimes boards are bad. I’ve owned several ASUS boards over the years and for the most part I have been very satisified with them. I like this Intel based board and for the price of $229 you are getting a lot. Load the board up with the I7 and 16GB of DDR3 and you have a nice system. Don’t forget the video card!. The board does support SLI/CrossfireX as you would imagine it would.

Drivers for ASUS P8Z77-V PRO

Bios

Chipset

Audio

VGA

LAN

Wireless

Sata
